Type CORDAFLEX (SMK)-V (N) SHTOEU Crane Vertical Reeling Cable

Type CORDAFLEX (SMK)-V (N) SHTOEU Crane Vertical Reeling Cable

The Type CORDAFLEX (SMK)-V (N) SHTOEU cable is engineered for flexible low voltage reeling applications under extreme mechanical stress.

It is specially designed for vertical reeling operations, particularly for use in spreader reeling applications in cranes.

Global Data

- **Brand**: CORDAFLEX (SMK)-V

- **Type Designation**: (N) SHTOEU-J/-O

- **Standard**: Based on DIN VDE 0250-814

- **Certifications / Approvals**: GOST-R

Design Features

- **Conductor**: Electrolytic bare copper, very finely stranded, classified as FS.

- **Insulation**: Special thermoplastic compound providing high stability, superior insulation resistance, and excellent gliding characteristics.

- **Core Identification**: Black insulation with light printed numbers, earth conductor green-yellow.

- **Individual Screen**: Braid screen made of tinned copper wires. Optimized transfer impedance at 30 MHz. Coverage is at least 60% for shielded cores and 80% for twisted pairs.

- **Core Arrangement**: Cores are laid up in a maximum of three layers. Central aramide support element enhances loading capability.

- **Sheath System - PROTOFIRM Special**:

- **Inner Sheath**: High-grade special compound based on PCP, yellow.

- **Anti-Torsion Braid**: Reinforced braid of polyester threads, vulcanized between sheaths for high strength.

- **Outer Sheath**: Special rubber compound based on PCP, yellow, abrasion and tear-resistant.

Advantages

- **Mechanical Stress Resistance**: Designed to withstand demanding vertical reeling applications.

- **High Stability and Insulation**: Thermoplastic insulation compound ensures excellent electrical characteristics.

- **Durable Sheath System**: The PROTOFIRM sheath system combines flexibility with high durability.

- **Enhanced Loading Capability**: Central aramide support element increases the cable’s load-bearing capacity.

The Type CORDAFLEX (SMK)-V (N) SHTOEU cable is ideal for industrial use where vertical reeling is required. Its robust construction ensures reliable performance in harsh conditions, making it a preferred choice for crane applications.

Note: This is just part of the standard parameters of our products. Please contact our Engineer if you need more. And the information contained within this webpage is for guidance only and is subject to change without notice or liability. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All pictures shown are for illustration purposes only. The actual product may vary. All the information is provided in good faith and is believed to be correct at the time of publication.
