Feichun M(StD)HOEU Flat Low Voltage Screened Cables for Advanced Industrial Applications
In today’s demanding industrial environments, the need for reliable, high-performance cables is more critical than ever. The Feichun M(StD)HOEU Flat Low Voltage Screened Cables are designed to meet these challenges head-on.
This innovative cable series combines advanced screening technology, robust materials, and exceptional flexibility to deliver unmatched performance in festoon systems, hoisting gear, and other industrial applications.
What sets the M(StD)HOEU cables apart is their ability to thrive in complex industrial environments, ensuring reliability in the face of mechanical stress, chemical exposure, and extreme temperatures.
These cables are a vital component for ensuring smooth operations in a variety of industries, from manufacturing to logistics.
Technical Architecture
Conductor Design
The M(StD)HOEU cables feature highly efficient copper conductors tailored for optimum performance.
| Feature | Specification |
| Material | Electrolytic copper |
| Class | Class 6 (up to 25 mm²), Class 5 (35 mm² and above) |
| Wrapping | Paper tape and PETP-film for added stability |
This design ensures excellent conductivity, even under high mechanical stress. The conductors are meticulously stranded to maximize flexibility, making them ideal for moving applications.
Insulation and Screening Technologies
The insulation material is a specially formulated 3GI3 rubber compound, ensuring durability and resistance to environmental factors.
Screening is another standout feature, offering protection against electromagnetic interference (EMI).
| Screening Feature | Benefit |
| ALU/PETP Foil | Provides robust EMI shielding |
| Tinned Copper Spinning | Ensures 85% coverage for maximum protection |
| Overlapping Design | Eliminates weak points in shielding |
These features make the cables ideal for environments with high electrical noise, ensuring seamless communication and power transmission.
Electrical Performance Characteristics
Voltage and Current Specifications
The M(StD)HOEU cables are engineered for superior electrical performance, meeting international standards.
| Parameter | Value |
| Rated Voltage | 0.6/1 kV (600/1000V) |
| Maximum Operating Voltage (AC) | 0.7/1.2 kV |
| Maximum Operating Voltage (DC) | 0.9/1.8 kV |
| AC Test Voltage | Designed for high dielectric strength |
Thermal Management
Temperature resistance is a hallmark of the M(StD)HOEU cable series.
| Temperature Condition | Value |
| Max Conductor Temperature | 90°C |
| Short-Circuit Tolerance | 250°C |
| Operating Range (Fixed) | -40°C to +80°C |
| Operating Range (Flexible) | -30°C to +80°C |
These specifications allow the cables to perform in diverse environments, from freezing conditions to high-heat applications.
Mechanical Resilience
Structural Integrity
Built for tough environments, the M(StD)HOEU cables excel in mechanical resilience.
| Feature | Specification |
| Maximum Tensile Load | 15 N/mm² |
| Bending Radius | Flexible to accommodate tight spaces |
| Travel Speed | Optimized for both motorized and non-motorized festoon systems |
These attributes ensure reliable performance in dynamic industrial setups, minimizing downtime and maintenance costs.
Application Domain
Ideal Usage Scenarios
The versatility of the M(StD)HOEU cables makes them suitable for a wide range of applications.
| Application | Environment |
| Hoisting Gear Systems | Smooth operation under high stress |
| Machine Tool Connections | Ensures precision and reliability |
| Outdoor Installations | Resistant to UV, oil, and chemicals |
| Wet/Damp Areas | Reliable performance in challenging conditions |
Comprehensive Product Range
The M(StD)HOEU cable series is available in a variety of configurations to meet diverse industrial needs.
| Variant | Features |
| Screened Power Cables | Superior power transmission |
| Screened Control Cables | Optimized for data transmission |
| Individually Screened Pairs | Enhanced signal integrity |
| Multiple Core Options | Flexibility for complex installations |
Compliance and Certification
The M(StD)HOEU cables meet the most rigorous industry standards, ensuring reliability and safety.
| Certification | Standard |
| UL Style 4540 | Recognized for global applications |
| DIN VDE 0250-809 | Trusted European standard |
| IEC 60228 / DIN EN 60228 | Alignment with international norms |
These certifications provide peace of mind for engineers and procurement professionals, confirming the cables' quality and safety.
Technical Problem-Solving Insights
Installation Considerations
To maximize the benefits of M(StD)HOEU cables, proper installation practices are crucial.
Environmental Adaptation: Ensure compatibility with ambient conditions, including temperature and exposure to chemicals.
Bending Radius: Adhere to specifications to prevent damage.
Performance Optimization: Use recommended accessories and follow manufacturer guidelines.
Comparative Advantage Analysis
The M(StD)HOEU cables stand out in the market due to their advanced features:
| Feature | Advantage |
| Superior Screening Technology | Ensures uninterrupted signal transmission |
| Exceptional Flexibility | Reduces wear and tear in moving systems |
| Wide Temperature Range | Suitable for diverse industrial setups |
| Chemical Resistance | Withstands exposure to harsh substances |
Conclusion
The Feichun M(StD)HOEU Flat Low Voltage Screened Cables represent the pinnacle of engineering for industrial applications. With their robust design, advanced screening technologies, and compliance with international standards, they are the ideal choice for demanding environments. Whether it’s ensuring precision in machine tools or reliability in outdoor installations, these cables deliver unparalleled performance.
For engineers, specifiers, and procurement professionals, choosing the M(StD)HOEU cables means investing in a future-ready solution that minimizes risks, enhances efficiency, and drives operational success.
Discover the Feichun difference today.
Note: This is just part of the standard parameters of our products. Please contact our Engineer if you need more. And the information contained within this webpage is for guidance only and is subject to change without notice or liability. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All pictures shown are for illustration purposes only. The actual product may vary. All the information is provided in good faith and is believed to be correct at the time of publication.
